Character 12864
PRODUCT TYPE Graphic dot matrix LCD module
APPLICATION instrumentation
Display Mode: Positive/ Negative
The shape size: 93.0mm×70.0mm×13.5mm
Effective area size: 72.0mm×39.0mm
Controller: NT7108C
Interface pattern: 8-BIT 6800
Process: COB
Interface Pins : 20Pins
Operating Temp: -20 to +70 Celsius
Storage Temp: -30 to +80 Celsius
