0.96 inch display-TG096000AR13A

0.96 inch display-TG096000AR13A

Resolution: 80*160
Interface: SPI
Display mode: Transmissive
OLED display
0.96″ display suitable for oximeters & Smart Bracelet, etc.
Support customization

Share to:

0.96 inch display-TG096000AR13A

0.96 inch small TFT LCD display

0.96 inch display-TG096000AR13A

0.96 inch display-TG096000AR13A



Item 0.96inch TFT module display
Model No TG096000AR13A
Resolution 80×160
Outline Dimension 13.5(H)x27.95(V)x1.5(D)
Active Area(mm) 10.8(H)x21.7(V)
Brightness 300nits
Viewing Angle All
Interface 4 Line SPI
Driving IC ST7735S
Display Mode Transmission / Normally Black
Operating Temperature -20℃~70℃
Storage Temperature -30℃~80℃
Touch screen Can custom resistive and capacitive touch screen

0.96 inch display-TG096000AR13A



80X160
4 Line SPI
small / Tiny display
ST7735S
